U Tech Dynamix Services

Specialized Utilities Management

High value property assests

Installation and Commissioning of Smart Meter Projects

Control Centre Application

Grid Visibility & Control, NES Technology

UAS NES Meter Hardware Sales

Hosting Services for property owners, utilities managers and Utilities

Normal Utilities Management

Hosting

Account Management System

Smappee Technology Solution Sales

U Tech Dynamix Technology & Systems

UAS NES System Software
UAS NES Element Manager
UAS NES Provisioning Tool
UAS NES Powerline testing tool and software
UAS NES "web services"
Vodacom Environment
Dedicated APN
Billing System
Prepaid System
Wallet System
Modem - design and integration with NES Technology
MEP - Application design and integration with UAS NES Technology
Control Centre Application
Account Management System
Smappee App

U Tech Dynamix Products

Proven, Secure, Multi-Application

  • Enhanced Security
  • UC-3 Compliant Disconnect Switch
  • Larger Memory for More Data Storage
  • Multiple MEP Connections and Flexible I/O options
  • Cutting Edge Host Processor for Future Smart Grid Application Expansion
  • Innovative and Customer Friendly Mechanical Design

Gen 4 Single Phase Meter Features

Proven, Secure, Multi-Application

  • Enhanced Security.
  • UC3 Compliant Disconnect Switch.
  • Larger Memory for More Data Storage.
  • Tamper resistant security chip for key storage.
  • Secure remote firmware upgrades.
  • Multiple MEP Connections and Flexible I/O options.
  • Cutting Edge Host Processor for Future Smart Grid Application Expansion.
  • Innovative and Customer Friendly Mechanical Design.
  • Power quality measurements include: voltage, current, frequency, power factor, Total Harmonic Distortion (THD).
  • 4×16 channels of load profile data; each with independent configuration of interval, size and collection settings.

IEC Poly Phase Smart Meter Key Features

Proven, Secure, Multi-Application

The MTR 3000 P2P meters support the P2P Gateway Module: a modem-equipped device that can be used to connect to NES System Software and commission the meter over a cellular network. P2P functionality provides the following additional benefits:

  • 2G / 3G modem support.
  • Future ready modular design for 4G modem.
  • IPv4 support.
  • Security: TLS 1.2 PSK using AES256- SHA384- ECDHE (RFC5246 and RFC5489). Remote key changes are fully supported.
  • Open Smart Grid Protocol (OSGP) P2P Protocol: More efficient message size compared to other protocols.
  • Tamper detection and protection for both the communication module and SIM card.
  • Hot Swap Support: Meter does not need to be powered down to install/replace the P2P Gateway Module. No loss of electrical service on Module replacement.
  • Last Gasp Outage Notification.
  • SMS Shoulder Tap Wakeup (future feature).
  • FOTA: Over-the-air firmware upgrades for the modem and meter (future feature).
  • Internal/External antenna options.

Point-to-Point (P2P) Cellular Metering Features

Proven, Secure, Multi-Application

  • Energy measurement technology highly resistant to magnetic fields.
  • Complex multi-tariff energy measurements configurable to time of day, weekends, holidays and seasonal changes.
  • Configure and store up to 4×16-channels of load profile data.
  • Power quality measurements include: voltage, current, active power, reactive power, power factor.
  • Secure remote firmware upgrades.
  • Connect to auxiliary meters (gas, water, heat) and grid devices.

IEC CT Smart Meter Features

Proven, Secure, Multi-Application

  • Low Voltage Grid Mapping – Map meter, segment, feeder and transformer associations and report it to the system.
  • Fast Commissioning – Commission supported meters in single message exchange.
  • App Distribution Platform – Support for remotely and securely adding distributed applications and device/ sensor support drivers in the field.
  • Outage Detection – Backup power and quick burst message to provide Last Gasp notification to system software regarding a transformer outage on 1 or more phases.
  • Flexible and Secure Connections – WAN communication using any wired or wireless IP-capable network, supports data authentication and encryption on all data channels. Enhanced connectivity and modularity via USB.

DCN 3000 Distributed Control Node Features
